Switch-Pros replaces a bundle of relays with one sealed power module and a compact touch panel. Program each switch in the free iOS or Android app: on/off or momentary, strobe, ignition or battery sense, dimming, and a master switch that can fire several outputs together.
Tough Trucks stocks the SP9100, the RCR-FORCE 12, and the American Flag RCR-Touch covers. We fit them at Arundel and Mackay, or you can install the kit yourself.
SP9100
The SP9100 is the 8-switch system. Eight outputs share 125 amps: switches 5–8 are rated at 35A and switches 1–4 are rated at 20A. The panel is 4 × 2 × 0.375 in (102 × 51 × 9.5 mm). The power module is about 6 × 3 × 0.5 in, sealed to IP67, and rated from −40°C to 125°C. Idle draw is 5.5 mA and sleep is 3 mA.
The kit includes the panel, the power module, a standard RCR-Touch 8 cover, an 11 ft (3.4 m) communication cable, a 125A fused power cable, the output harness, switch legends, and mounting brackets. Backlighting is RGB. Status indicators are amber. Bluetooth is 4.1, and the app shows battery voltage.
RCR-FORCE 12
The RCR-FORCE 12 is the 12-switch system, with 17 outputs and 150 amps total. Four outputs are rated at 35A and one at 30A for high in-rush loads such as fans and motors. Eleven outputs are rated at 15A, and one is a 2A low-side output. Up to four outputs can be linked to one switch.
The panel is 4 × 3 × 0.375 in (102 × 76 × 9.5 mm). The power module is 7.1 × 3.5 × 0.625 in, sealed to IP67. The kit includes the RCR-Touch 12 cover. Switch-Pros states this system can be used to start the vehicle.
American Flag covers
The RCR-Touch snaps over the panel so you can find a switch with gloves on, or while the truck is moving. The 8-switch cover fits the SP9100 and the earlier SP8100. The 12-switch cover fits the RCR-FORCE 12. Both flag listings are the cover only. The switch panel is not included. A standard RCR-Touch is already packed with each system. These covers are the American Flag pattern.
Questions
What is the difference between the SP9100 and the RCR-FORCE 12?
The SP9100 has 8 switches and 8 outputs, at 125A total. The RCR-FORCE 12 has 12 switches and 17 outputs, at 150A total, including high in-rush circuits and a low-side output.
Does the RCR-FORCE 12 include the touch cover?
Yes. The standard RCR-Touch 12 is part of the kit. The American Flag 12 cover is a separate listing if you want that pattern, or a replacement if the standard cover is lost.
Which cover fits the SP9100?
The RCR-Touch 8. A standard one is included with the SP9100 kit. The American Flag 8 listing is the cover only.
Can I run the panel from my phone?
Yes. Both systems use Bluetooth and the free Switch-Pros app on iOS and Android. You can program the switches and read battery voltage in the app.
Will this fit my truck?
These are universal 12-volt systems, not a vehicle-specific harness. Tough Trucks fits them at Arundel and Mackay. Call 07 5500 0095 if you want the panel mounted in a dash or overhead console.
Do I still need relays?
No relay box. The power module switches the accessories. The high in-rush outputs on the RCR-FORCE 12 can drive fans and motors directly.
